HEAVY DUTY WIDE BELT SANDER / DOUBLE HEADS
- :BKM-52RK
- :SEMAC - Quoc Duy
- :12 Months
- :Call
- :
 |  |
Heavy Duty Wide Belt Sander / double heads
Model: BKM-52RK
|
FEATURES
|
|
|
Computerized table-elevation.
Digital readout for the opening between the conveyor table and contact roller.
The contact roller is rubber coated and dynamically balanced.
Photoelectric cell controlled sanding belt tracking.
Automatic machine stop in the event of air failure or sanding belt breakage.
Quick replace sanding belt device.
|
|
|
Specifications
|
|
|
Max. working width
|
: 1270 mm
|
|
Max. working thickness
|
: 127 mm
|
|
Main motor (standard)
|
: 30HP, 20 HP(Opt.40HP,30HP)
|
|
Feed motor
|
: 3HP
|
|
Table hoist motor
|
: ½ HP
|
|
Feed speed range
|
: 6-25±5% m/min
|
|
Sanding belt size
|
: 1295 x 1905 mm
|
|
Working pressure
|
: 6 kg/cm²
|
|
Net weight
|
: 3050kgs
|
|
Gross weight
|
: 3500kgs
|
|
Machine size (LxWxH)
|
: 2370x2100x2030 mm
|
|
Packing size (LxWxH)
|
: 2450x2160x2250 mm
|
