ROTATION BRUSH SANDER MACHINE
ROTATION BRUSH SANDER MACHINE
Model: SM-1300-7S
| Specifications | |
|
Max. Working width
|
: 1300 mm
|
|
Max.Working thickness
|
: 100 mm
|
|
Lifting power
|
: 7 x 0.25 Kw
|
|
Intergral lifting power
|
: 1.5 Kw
|
|
Conveyor motor
|
: 2.2 Kw
|
|
Conveyor speed
|
: 5 – 20 m/min
|
|
Swing motor
|
: 6 x 0.2 Kw
|
|
Screw roller speed
|
: 80 – 550 rpm
|
|
Screw roller motor
|
: 3 x 2.2 Kw
|
|
Screw roller number
|
: 3 set
|
|
Dia. Screw roller
|
: Ø300 mm
|
|
Adjustable brush speed
|
: 80 – 450 rpm
|
|
Disc brush motor power
|
: 6 x 0.75 Kw
|
|
Number of brushes
|
: 6 x 3 set
|
|
Dia. Brush tray
|
: Ø180 mm
|
|
Horizontal roller motor
|
: 2 x 1.5 Kw
|
|
Horizontal roller number
|
: 8 set
|
|
Dia. Horizontal roller
|
: Ø330 mm
|
|
Total power
|
: 26.95 Kw
|
|
The wind speed
|
: 22 – 30 m/s
|
|
Vacuum mouth
|
: 11 x 100 mm
|
|
Vacuum
|
: 11 x 635 m3/h
|
|
Net weight
|
: 5450 kgs
|
|
Machine size
|
: 4850x2150x2275 mm
|
