STRAIGHT LINE RIP SAW
Straight line rip saw - This machine is a precision straight line rip saw, which is used prior finger jointing process. - After machining, workpieces’ side is perfectly straight with flat surface. - Rapid finishing speed for high efficiency. - Using saw blade at the bottom for safe and accurate sawing. - Eight holding rolls to maintain the workpiece stable with the track.
- :JR-18
- :Taiwan
- :12 month
- :Call
- :
 |  |
STRAIGHT LINE RIP SAW
Model: JR-18
| FEATURES | |
|
- The feeding quide board can be moved rapidy and locked easily - The sturdy frame and rigid construction of the machine anables it to be continuously operated for a long duration - The double-track chain conveyer has wide working surface so that the material can be cut straightly, precisely, and smoothly - The auto lubrication device is equipped with an alarm light which send signals upon a lack of lubrication oil to increase the durability of the machine |
|
| SPECIFICATIONS | |
|
Model
|
JR 18
|
|
Arbor motor
|
10 HP
|
|
Saw blade diameter
|
Ф 355 – Ф 405 mm
|
|
Saw arbor diameter
|
Ф 50.8 mm
|
|
Working thickness
|
95 mm
|
|
Distance between saw& column
|
660 mm
|
|
Spindle rotation
|
3600 Vòng/phút
|
|
Feeding motor
|
2 HP
|
|
Feeding speed(variable)
|
11 -26 m/phút
|
|
Table area
|
2000 x 1160 mm
|
|
Net weight
|
1700 kg
|
|
Machine size
|
2270x1750x1650 mm
|
