4 SIDE SANDER
- :GF-506U4
- :Taiwan
- :12 months
- :Call
- :
 |  |
4 SIDE SANDER
Model : GF-506U4
| Features | |
|
· Applied for straight line stock and curved workpiece, sanding 4 sides effectively and rapidly with one pass · Suitable for ordinary and sealer sanding · Switch for sanding forward or reverse to get the best effect in workpiece · With infinitely variable speed of sanding belt and feeding |
|
| Specification | |
|
+ Vertical sanding belt drive motor
|
: 1HP x 4P x 2 pcs
|
|
+ Sanding belt speed
|
: 0 – 565 m/min
|
|
+ Sanding drum size
|
: Ø 100 – 150 mm
|
|
+ Sanding belt size
|
: 152 x 635 mm
|
|
+ Sanding belt oscillation range
|
: Electric
|
|
+ Horizontal sanding motor
|
: 120 mm
|
|
+ Sanding belt speed
|
: 2 HP x 4P x 2
|
|
+ Sanding drum size
|
: 0 -980 m/min
|
|
+ Sanding belt size
|
: Ø 175 x 150 mm
|
|
+ Sanding belt oscillation range size
|
: 152 x 850 mm
|
|
+ Feeding motor
|
: ¼ HP x 4P x 4 pcs
|
|
+ Feeding speed
|
: 0 – 22 m/min
|
|
+ Feeding roller size
|
: Ø 75 x 75 mm
|
|
+ Feeding roller number
|
: 4 pcs
|
|
+ Working thickness
|
: 15 – 75 mm
|
|
+ Working height
|
: 25 – 75 mm
|
|
+ Working length
|
: 600 – 1500 mm
|
|
+ Machine size
|
: 1350 x 1100x 1630 mm
|
|
+ Packing size
|
: 1450 x 1200 x 1830 mm
|
|
+ Net weight
|
: 860 kg
|
|
+ Gross weight
|
: 980 kg
|
