APPLIES THE FULL-AUTOMATIC EDGE BANDING MACHINE
APPLIES THE FULL-AUTOMATIC EDGE BANDING MACHINE
Model: SM-528E
|
Specification
|
|
|
Thickness of roling edge-banding belt
|
0.4-3mm
|
|
Height of roling edge-banding belt
|
12-55mm
|
|
Workpiece thickness
|
10-50mm
|
|
Air pressure
|
0.7Mpa
|
|
Compressed air usage
|
0.3m³/min
|
|
Power if accessorial heating device
|
0.12kw
|
|
Fine trimming motor
|
0.7kw ×2 12000r/min 200Hz
|
| Machine size | 3000 x 700 x 1500mm |
