MODEL

TPS-10CS

TPS-10C

TPS-10CH

Max. cutting length

3250 mm

3200 mm

Max. cutting height

80 mm

0 - 100 mm

Main sawblade diameter

Ø 355 mm

Ø 405 mm

Arbor diameter

Ø 30 mm

Ø 60 mm

Main sawblade speed

4800 rpm

3910 rpm

Scoring sawblade diameter

Ø 180 mm

Ø 176 mm

Scoring sawblade speed

Ø 30 mm

Ø 45mm

Scoring sawblade speed

6500 rpm

5100 rpm

Forward speed

9- 37m/min

12- 16 -21 – 26m/min

5 – 100 m/min

Return speed

67 m/min

24 -32-42 -52 m/min

120 m/min

Main sawblade motor

  13 HP

20 HP

Scoring sawblade motor

3 HP

High pressure blower motor

3 HP

Automatic feed motor

1 Kw (  servo)

2 Kw ( AC servo)

Pusher feed speed

30m/min

12m/min

5-80 m/min
