Vacuum Press Assistant

Vacuum Press Assistant
  • :Assistant
  • :Turkish
  • : 12 month
  • :Call
  • :



Vacuum Press Assistant



ASSISTAN VAKUM MEMBRAN PRES, Together with lining of kitchen cabinets, door leafs, chairs and table leafs made of high glass pp leather, PVC foil, transfer foil natural lining with Assistant vacuum membrane press, also lines membrane and nonmembrane 3-d elegant, acute angled slopes, sharp corners, surfaces and edges at the same time in not only furnishing but also in buildings, automotive, steel covering and plastic industry.

1. Systems patented to HAKİ SABIR.

2. Plc controlled automatic usage

3. Ergonomic lift system

4. Manufacture safety systems in accordance with CE standard.

5. Homogenous and economic heat distribution and control

6. Long life structure and higher product quality.

7. Minimum wastage and time saving

8. Can press up to 30 cm thickness

9. Hot air circulation system

10. Process time is between 2-5 minutes.

11. Plc usage options in Turkish, English and Russian.

12. 2 years warranty with nonproblematic equipment, machinery safety systems.

Used in the working area
2550 x 1250 x 160 mm
Maximum extrusion pressure
1. kg / cm²
Vacuum pressure
37 ton – 750 milibar
Vacuum Capacity
45 m³/h
Vacuum Motor Power
2 kW – 1400 rpm
Pressing Engine
0.75 kW – 1400 rpm
Resistance heating power
34 x 800 W
Total power
30 kW
Machine dimensions
1600 (e) x 2400 (y) x2700 (b)
Machine weight
760 kg
