Feature
Working way: when the push rod back, scan the draw lines on the workpieces, and input the length data in the PC for the optimization. Designation Priority: The designation length of workpieces in the cut list can be cut first, Priority can be given to materials in short supply in production line. Fixed Cutting: Do not optimize, follow up the lít from up and down of the order list, it is suitable for the no defects materials. Largest Value: Based on the prices in the list, software combines the most valuable cutting methods, which can maximize the utilization value of the material. Defect cutting: The sawing position is marked on the wood by manually, and the equiment is automatiscally finds the line position ( this way working, only follow up the drawing lines cutting, not optimizing. Supporting excel file for the import order material, and support customize the form format. Cutting list can add barcode, and print barcode, two-dimensional code free setting
Specifications
Working width	: 10-400 mm
Working thickness	: 10-120 mm
Working length	: 6000 mm
Table height	: 850 mm
Scanning speed	: 80 m/min
Workpiece length scanning device	: infrared sensor (SICK)
Servo motor to push	: INVT
Servo motor to feed	: 0.75 Kw
Convenyor motor	: 0.75 Kw
Sawblade motor	: 7.5 Kw
Dust collector diameter	: 100 mm x 1pcs
Total power	: 9 Kw
System	: WIMDOWS 7
Net weight	: 8550x2000x1800 mm
Machine size	: 1200 kg
