Feature
+ Cuts dovetailed tenons/mortises simultaneously for accurate jointing + Dovetailed width and depth are adjustable. + Continuous tenoning motion + Automatic motion cycle provides efficient, economical operation + High spindle speed 20.000 rpm + Simple to operate, simple to maintain + 3 feed speeds change suitable for cutting various wood materials
Specifications
Tenon thickness	10 – 20 mm
Tenon width	10 – 18 mm
Tenon depth	10 – 20 mm
Spindle vertical adjustment	30 mm
Max. workpiece sizes	1500 x 480 mm
Collect chuck capacity	f12 mm
Number of air clamps	4 pcs
Spindle speed	21.500 rpm
Spindle motor	2 HP
Working air pressure	6 kg
Machine size	1270 x 780 x 1330 mm
Packing size	1370 x 880 x 1450 mm
Net weight	480 kg
Gross weight	600 kg
