Specifications
Max. working width	1300 mm
Working thickness	100 mm
Adjustable brush speed	80 – 450 rpm
Screw roller speed	80 – 550 rpm
Conveyor speed	5-20 m/ min
Each group of the lifting power	5* 0.25 Kw
Intergral lifting power	1.5 Kw
Disc brush motor power	1*1.1 Kw
Disc brush motor power	4*1.5 Kw
Screw roller moter	2*2.2 Kw
Horizontal roller motor	2*1.5 Kw
Conveyor motor	2.2 Kw
Swing motor	5*0.2 Kw
Total power	20.45 Kw
Screw roller number	2 set
Dia. Screw roller	Ø300 mm
Brush plate number in each group	4*3 set
Dia. Brush tray	Ø180 mm
Horizontal roller number	8 set
Dia, Horizontal roller	Ø330 mm
Vacuuming mouth	9xØ100mm
The wind speed	22 – 30 m/s
Net weight	4850 kg
Machine size	3750x1980x2180 mm
