AUTOMATIC 2-HEAD DRILLING CUTTING MACHINE

Model : SM 2400 2CDI

Specifications
Max workpiece length	: 2500 mm
Min workpiece length	: 250 mm
Max workpiece thickness	: 40 mm
Max workpiece width	: 150 mm
Left cutting motor	: 2.2 kw
Right cutting motor	: 2.2 kw
Left vertical drill motor	: 1.5 kw
Right vertical drill motor	: 1.5 kw
Left horizontal drill motor	: 1.5 kw
Right horizontal drill motor	: 1.5 kw
Left oblique drill motor	: 1.1 kw
Right oblique drill motor	: 1.1 kw
Servo motor feeds the workpiece (L)	: 0.75 kw
Servo motor feeds the workpiece R	: 0.75 kw
The motor returns the workpiece (L)	: 900 w
The motor returns the workpiece R	: 900 w
Length adjustment motor	: 0.37 kw
Machine size	: 3900 x 2100 x 2100 mm
