AUTOMATIC CARBIDE SAW GRINDER
AUTOMATIC CARBIDE SAW GRINDER
Model: SJ 18
Features | |
- Grinding all kinds of grinding teeth for 1 times . |
|
Specifications | |
Grinding Outer
|
Ø150 ~ Ø 700 mm / 6”~ 27.6”
|
Saw bore dia
|
Ø 10 ~ Ø 120 mm
|
Blade thickness
|
8 mm
|
Tooth Pitch
|
8 ~ 70mm
|
Height difference
|
3 mm
|
Peripheral speed
|
25 m/s
|
Grinding speed
|
0.5 ~ 10 mm/s
|
Grinding ability
|
20 teeth / min
|
Clearance angle
|
6°~ 45°
|
Rake or Hook angle
|
0°~ 40°
|
Bevel grinding at the tooth top
|
0°~ 45°
|
Bevel grinding at the tooth face
|
0°~ 30°
|
Connected load
|
1.7 KW / 2.3 HP
|
Grinding wheel outer * bor
|
Ø 125mm* Ø 32 mm
|
Machine size LxWxH
|
1600x1600x1800 mm
|
Packing size LxWxH
|
1730x1670x1900 mm
|
NW/GW
|
650 / 800 kgs
|
Rev. speed of grinding whee
|
5000 rpm
|
Grinding power
|
0.75 KW/ 1 HP
|
Coolant pump motor
|
0.1 KW/ 1/8 HP
|
