DOUBLE END TENONER ROBOT

MODEL: SMBY 5260

Specification
Working length	: 160 - 2000 mm
Working width	: 20 – 120 mm
Working depth	: 8 -50 mm
Horizontal adjustment angle	: ±45°
Vertical adjustment angle	: ±45°, -10°
Motor spindle	: 6 Kw x 2 piece
Feed spindle	: 12000 rpm
Motor servo axis X	: 2 Kw x 2 piece
Motor servo axis Y	: 1.5 Kw x 2 piece
Motor servo axis Z	: 1.5 Kw x 2 piece
Motor servo axis C	: 0.75 Kw x 2 piece
Motor servo axis B	: 0.75 Kw x 2 piece
Motor adjustment range	: 1 Kw
Motor servo	: Delta
Total power	: 23 Kw
Air Compress	: 0. 4 – 0.6 Mpa
Machine weight	: 3000 Kg
Machine size	: 4900 x 2200 x 2100 mm
