FILLER REPLENSHERS
FILLER REPLENSHERS
Specifications | |||
Model
|
TS- W2TA-M
|
TS- W3TA-M
|
TS- W4TA-M
|
Max. with of coating
|
610 mm
|
920 mm
|
1290 mm
|
Min. length of coating
|
2- 80 mm
|
||
Workpiece
|
300 mm
|
||
Conveyor belt speed
|
10 – 20m/phút
|
Other speeds are available
|
|
Coating rollers sizes
|
Ø205x 780 mm
|
Ø205x1100mm
|
Ø205x1450 mm
|
Smoothing rollers sizes
|
Ø150x 780 mm
|
Ø150x1100mm
|
Ø150x1450 mm
|
Filler roller sizes
|
Ø200x 780 mm
|
Ø200x1100mm
|
Ø200x1450mm
|
Coating rollers motor
|
0.75 Kw
|
0.75 Kw
|
1.5 Kw
|
Smoothing rollers motor
|
0.37 Kw
|
0.37 Kw
|
0.75 Kw
|
Filler roller motor
|
0.37 Kw
|
0.37 Kw
|
0.75 Kw
|
Conveyor belt motor
|
0.75 Kw
|
0.75 Kw
|
1.5 Kw
|
Elevation motor
|
0.18 Kw
|
0.18 Kw
|
0.18 Kw
|
Pump
|
3/4”
|
||
Machine size
|
1300x1770x1440 mm
|
1300x2100x1440 mm
|
1300x2385x1440 mm
|
