LONGITUDINAL VENEER SPLICERS
the longitudinal veneer splicer, VeneerPlus, is equipped with the integrated gluing system inside. It’s particularly suitable for the furniture industry and high-end decorative plywood. After the well-cut veneer strips are aligned evenly by the synchronized infeed rollers, the veneers are directly conveyed to the singular gluing unit for gluing edges and then transported to the heating section for glue curing.
- :VeneerPlus
- :Taiwan
- :12 months
- :Call
- :
 |  |
LONGITUDINAL VENEER SPLICERS
Model: VeneerPlus
| FEATURES | |
|
- complied with European CE safety standards
- precise cooling system for prolonging glue pot life
- rigid welded machine body for stable splicing work
- automatic lubricating system to extend the guide life
- easy adjustment and quick access of integrated gluing system
- special-designed pressurized and heating mechanical structures
- motorized driven infeed discs instead of traditional rollers for smoother infeed
the latest designed transporting chains of engineering plastics for reducing the heat on veneers
- reflective photocell sensor in the infeed section to ensure a perfect alignment of the jointed veneers
- narrow heating zone with individual temperature controllers for minimizing the heat to avoid deforming splicing veneers
- SSR (solid state relay) heating controller, different from the heater with traditional m
|
|
| SPECIFICATIONS | |
|
Veneer Strip Thickness
|
0.35~2.5 mm
|
|
Veneer Strip Length
|
350mm
|
|
Veneer Strip Width
|
45mm
|
|
Production Speed
|
45m/min
|
|
Electric Power
|
5.5 kw
|
|
Compressed Air
|
5 bar
|
|
Heating Temperature
|
100 ~ 220 °C
|
|
Dimensions (L x W x H)
|
2190 x 2070 x 1590 mm
|
|
Net Weight
|
1500 kgs
|
