OPTIMIZING CUT OFF MACHINE

MODEL:SC 230S

SC-230S

Features
A profitable performer for safe, high speed and high efficiency production. A wide variety of cutting modes to meet your flexible cutting requirements. Lower labor cost and time cost! Increase production efficiency and economic benefits! This machine uses a fluorescent crayon for marking, incorporated with a photocell sensor to detect defective parts automatically. High performance AC servo motor drives the infeed conveyor system, providing precise positioning of the workpiece. Multiple language displays : Chinese, English and other languages(Option). Various lengths and quantities of cut can be set as desired. Data can be memorized. (36 sizes in a Job Sheet. Total 100 Job sheets) Variety of cutting modes to meet your flexible cutting requirements. SC-230A : Sawblade elevation by Air Cylinder. SC-230W: Sawblade elevation by Servo motor.
Specifications
Cutting thickness	: 12~75 mm
Cutting width	: 20~230 mm
Min. Cutting size	: 50 mm
Min. Infeed length	: 260mm
Min. timber cross section	: 30x12 mm
Max. Timber cross section	: 230x40 / 160x75 rpm
Max. Feeding speed	: 150 (Air cylinder) M/min
	: 190 (Servo) M/min
Cutting speed (Note1)	: Air cylinder type 138 pcs/min
	: Servo (option) : 185pcs/min
Sawblade diameter	: Ø 505 mm (20”)
Saw arbor diameter	: Ø 25.4 mm (1”)
Spindle speed	: 4000 rpm
Feeding servo motor	: 10HP (7.5Kw)
Saw drive motor	: 10HP (7.5Kw)
Outfeed motor	: 1 HP (750W)
Elevation motor	: 1/4HP x2
Air pressure	: 5~6 kg/cm2
Dust hood outlet diameter	: 125 mm (5”)x3
Machine dimensions (LxWxH)	: 19600x1862x1750 mm
Machine Net weight	: 3100 kgs
Machine Gross weight	: 3600 kgs
