SANDING MACHINE PROFILE
SANDING MACHINE PROFILE
Specifications | |
Purpose | :Automatic edge rub of the details straight or the edge of the table |
Working width limit | : 50 ~1800 mm |
Minimum workpiece length (Feeding roller type embryos). | : 250 mm |
Minimum workpiece length (Roll conveyor type embryos) | : 100 mm |
Working thickness limit | : 50 ~80 mm |
Abrasive tape width | : 30 ~100 mm |
Abrasive tape length | : 2450 mm |
Abrasive tape Slope | : - 450 ~ + 900 |
Abrasive tape transmission motor / Speed | : 2,2 kW x 2 (0 ~ 1800 revolutions / minute) |
Workpiece conveyor transmission motor / Speed | : 0.75 Kw (3 ~ 28 m/ minute) |
Workpiece conveyor width | : 80 mm |
Shaft rough broom transmission motor / Speed | : 2.2KW x 2 (0 ~ 1800 revolutions / minute) |
Rough broom inclination | : + 900 ~ + 1800 |
Oscillation shaking motor | : 0,1 Kw x 2 |
Origin | :Taiwan |
