SINGLE BELT ROUND ROD SANDING MACHINE
SINGLE BELT ROUND ROD SANDING
Model: CF-80B
Feature |
|
- A single belt sander that suitable for sanding round rod from Ø5 to Ø80mm in diameter. - Priced for economical and intermediate finish, yet built for versatile sanding operation for wood, rattan, metal, acrylic, graphite...... - Fatest feed speed the range from 6 to 20 meters per minute. - Change abrasive belt in seconds. - Same high quality features as CF-80B2 Double Belt Round Rod Sanding Machine. |
|
Specification | |
Range of working diameter | Ø5-Ø80 mm |
Range of working length | 100 - 1000 mm |
Drive motor | 3 HP |
Vaccum suction motor | 1/2 HP |
Sanding belt size | 125 x 1860 mm |
Belt speed | 18m / giây |
Feed speed | 6 - 20m / phút |
Machine size (L x W x H) | 750 x 510 x 1340 mm |
Machine size (L x W x H) | 840 x 650 x 1520 mm |
Net weight | 290 kg |
Gross weight | 350 kg |
