The Final Sanding / Denibbing Machine
The Final Sanding / Denibbing Machine
Model: BKM -1000H, BKM -1300H
Specifications | ||
MODEL
|
BKM -1000H
|
BKM -1300H
|
Max. working width
|
900 mm
|
1270 mm
|
Max. working thickness
|
150 mm
|
150 mm
|
Lateral spindle motor
|
2HPx2
|
3HPx2
|
Vertical spindle motor
|
½HPx4
|
½HPx5
|
Feed motor
|
2HP
|
2HP
|
Table hoist motor
|
½HP
|
½HP
|
Variable feeding speed
|
3-12 m/min
|
3-12 m/min
|
Diameter of sand brush
|
305 m/min
|
305 m/min
|
Working pressure
|
7 kg/cm
|
7 kg/cm
|
Net weight
|
2280 kgs
|
2800 kgs
|
Gross weight
|
2470 kgs
|
3300 kgs
|
Machine size
|
2800x2200x1660 mm
|
2800x2500x1660 mm
|
Packing size
|
2850x2250x1880 mm
|
2850x2550x1880 mm
|
