Features
Double side processing, double the efficiency, synchronus conveying device, standardized edge banding process, flexible edge banding. Left and right conveying device, through-type processing, shorten panel distance, maximize the utilization of each banding machine
Specifications
Panel length	: >= 300 mm
Panel width	: >= 300 mm
Panel thickness	: 10-60 mm
Tape thickness	: 0.4-3 mm
Tape width	: 13 -63 mm
Feeding speed	: 15-18-20 m/min
Total power	: 25.4 Kw
Working pressure	: 0.65 Mpa
Machine size	: 6320x4810x1700mm
Net weight	: 4500kg
