Specifications
+ Maximum Width Of Cut	: 405mm
+ Maximum Thickness Of Cut	: 200mm
+ Minmum Thickness Of Cut	: 8mm
+ Minmum Lenght Of Cut	: 100mm
+ Knife Nos. On Bottom Cutterhead	: 120pcs
+ Knife Sizes	: TCT 15x15x2.5mm
+ CutterHead Speed	: 6000RPM
+ Variable Feed Speed	: 8-40m/min
+ Dust Hood Outlet Diameter	: 5" x 1
+ Table Surface Area	: 480mmx2170mm
+ Buttom Cutterhead Drive Motor	: 7.5HP
+ Feed Drive Motor	: 2HP
+ Upper Mechanism Elevation Motor	: 1/2HP
+ Machine Dimensions	: 1860x850x1650mm
+ Net Weight	: 1300kg
+ Packing Dimensions	: 1940x930x1890mm
+ Gross Weight	: 1450kg
Video

HIGH SPEED BEVEL SPINDLE AUTO JOINTER 0.4M

HIGH SPEED BEVEL SPINDLE AUTO JOINTER

Model: GT-400J
