Specification
Max. Working width	: 700
Min. Working length	: 310
Working thinkness	: 3 – 110 mm
Dimension of abrasive belt	: 730 x 1900 mm
Feeding speed	: 5 – 30 m/min
Motor #1	: 15 kw
Motor #2	: 11 kw
Conveyor motor	: 1.5 kw
Lift table motor	: 0.37 kw
Rush roller motor	: 0.37 kw
Air pressure	: 0.6 Mpa
Exhaust volume requirement	: 5000 m³/h
Total power	: 28.24 Kw
Machine size	: 1355 x 2164 x 1980 mm
Net weight	: 2100 kg

TWO HEAD WIDE BELT SANDER MACHINE

TWO HEAD WIDE BELT SANDER MACHINE

Model: SM-700RR
