COMPUTER BANDSAW
COMPUTER BANDSAW
Model: SDJ-1500
| Specifications | ||
|
Model
|
SDJ-1500
|
SDJ-2000
|
|
Number of universal driving CNC shafts
|
03
|
03
|
|
Saw blade specification
|
5400x 16x0.8 mm
|
5340x16x0.8 mm
|
|
Saw wheel diameter
|
760 mm
|
760 mm
|
|
Saw blade rotation angle
|
± 90o
|
± 90o
|
|
Spondle power
|
7.5 kw
|
7.5kw
|
|
Max.working speed
|
0-20 m/phút
|
0-20 m/phút
|
|
Max.retraction speed
|
40 m/phút
|
40 m/phút
|
|
Working height
|
150 mm
|
150 mm
|
|
X-axis servo motor
|
2.0 kw
|
2.0kw
|
|
Y-axis servo motor
|
1.0 kw
|
1.0kw
|
|
Z-axis servo motor
|
0.4 kw x 2
|
0.4kw x 2
|
|
Max.working size
|
1500 x 1250 mm
|
2000 x 1250mm
|
|
Minimum turning radius
|
R= 60 mm
|
R= 60 mm
|
|
Working air pressure
|
100 mm x 2
|
100 mm x 2
|
|
Dust suction inlet
|
6 kg/cm3
|
6 kg/cm3
|
|
Electrical cubicle sizes
|
1050x550x1800 mm
|
1050x550x1800 mm
|
|
Machine head sizes
|
1000x900x2500 mm
|
1000x900x2500 mm
|
|
Machine sizes
|
4000x2200x1700 mm
|
5000x2200x1700 mm
|
