Specifications
Max. processing length	2500 mm
Max. processing thickness	50 mm
Max. milling depth	100 mm
Max. milling cutter diameter	180 mm
Milling cutter shaft diameter	Φ35
Boring shank diameter	Φ30
Milling shaft speed	9000 rpm
Drilling shaft speed	18000 rpm
Drilling head speed	12000 rpm
Milling shaft power	11KWx2
Milling cutter shaft power	5.5 Kw
Max. processing distance	100mm
Drilling shaft power	3.7 Kw
Total power	35.5 Kw
Air pressure	6 - 8 bar
Voltage	380V/50HZ
Net weight	3500 kgs
Machine size	4700 x 2300 x 1700 mm
Video

THRESHOLD MACHINE CENTER

THRESHOLD MACHINE CENTER

Model : SM-MT-2500-4/3

CNC TENONER MACHINE 3500 MM

5 AXIS CNC MORTISING AND TENONING MACHINE

CNC TENONER MACHINE

CNC TENONER MACHINE

CNC MITER MACHINE

CNC TENON AND MORTISE MACHINE

CNC 5 AXIS MACHINE

AUTOMATIC FEEDING AND PROCESSING CENTER
