Print Heads

Konica Minolta
512 nozzles (4 heads, up to 10 heads optional)

Drop Volume

14pl

Print Color

C, M, Y, K, Lc, Lm, White Ink, (top coat ink optional)

Print Resolution (dpi)

720 x 720
1440 x 720

Print Speed, m2/hr (ft2/hr)

6/7 colors
4 colors
6/7 color
4 color

Up to m2/hr (ft2/hr)

14.1 (150)
28.2 (301)
7.1 (75)
14.2 (150)

Print Area

2350 mm x 1250 mm (96 inch x 48 inch)

Max. Thickness

100mm (3.94 inch)

Ink Type

UV Curable ink

Media Handling

Flatbed moving gantry, Vacuum

Media Type

Foam Board, Acrylic sheet, Glass, Wood, Aluminium, Tile, etc.

Interface

Ethernet 10/100 Base T

RIP application

As RIP support

Dimension

4600 mm x 3750 mm x 2000 mm

Weight

2500 Kg

Package List

CoJet - 2612s Printer system, Maintenance Tools, Power Cable, ink, Vacuum Pump, Communication Cable, Operation Manual

Operation Environment

Temperature: 15-30° C (59-86° F), Humidity: 30-70% RH

Power Requirement

200-240 VAC, 50/60 Hz, 32A, 3 Phase

Air Source

5kg/cm, 30 L/min, Clean Dry Air

Warranty

Máy in: 1 Year, Đầu in: 6 months
