OSCILLATION MORTISER RECTANGULAR TENONER CNC
OSCILLATION MORTISER RECTANGULAR TENONER CNC
Model: SDC-1200-4-4/ SDC-2000-4-4
| Specifications | ||
|
Travel X Axis
|
: 1100 mm
|
: 1200 mm
|
|
Travel Y Axis
|
: 1200 mm
|
: 2000 mm
|
|
Travel Z Axis
|
: 220 mm
|
: 220 mm
|
|
Min. distance between two spindle
|
: 200mm
|
: 200 mm
|
|
Spindle speed
|
: 18000 rpm
|
: 18000 rpm
|
|
Spindle Motor
|
: 3.7 KW x 4
|
: 3.7 KW x 4
|
|
Travel servo motor
|
: 0.85 KW x 3
|
: 0.85 KW x 3
|
| Total power | : 18 Kw | : 18 Kw |
|
Machine dimension
|
: 2300 x 2230 x 1900 mm
|
: 3230 x 2230 x 1900 mm
|
|
Net weight
|
: 1300 kgs
|
: 1900 kgs
|
