STRAIGHT AND ANGLED EDGE BANDING MACHINE

Model: SMHC 4590

Specifications
Edge Thickness	: 1 – 1.5 mm
Panel Thickness	: 15 – 40 mm
Edge Width	: 20 – 70 mm
Pre milling	: 3 Kw x 1; 3.5 Kw x 1
Glue Pot Power	: 2.7 Kw
Head and Tail Cutting	: 0.55 Kw x 2
Top and Bottom Trimming	: 0.55 Kw x 2
Polishing	: 0.18 Kw x 2
Conveyor feeding	: 1.5 Kw
Total Power	: 13.26 Kw
Conveyor Speed	: 6 m/min
Voltage	: 380V/50Hz
Machine Dimensions	: 4600 x 1200 x 1550 mm
Weight	: 900 kg
