Specification
Planing width	10 – 230 mm
Planing thickness	7 – 160 mm
Feeding speed (inverter conttrol)	6 – 36 m/min
Min. length of cut	230 mm
Spindle speed	6000 rpm
Spindle diameter	Ø 40 mm
Adjustment of vertical spindle	60 mm
Adjustment of horizontal spindle	20 mm
Tool cutting circle, 1st bottom spindle, min. to max	125 – 160 mm
Tool cutting circle, vertical spindles, min. to max.	Ø 100 – 180 mm
Tool cutting circle, horizontal spindles, min. to max.	Ø 100 – 200 mm
Tool cutting circle, last bottom spindle, min. to max.	Ø 100 – 250 mm
Spindle motor	7.5 HP, 10 HP
Feeding motor (Inverter)	7.5 HP
Table adjustment	12 mm
Infeed table length	Ø 140 mm
Feed roller width	2 x 50 mm
Machine size	4670 x 1930 x 1800 mm
Packing zize	4820 x 2100 x 2120 mm
Net weight	4600 kgs
Gross weight	5200 kgs
Video

4 SIDE PLANER AND MOULDER

4 SIDE PLANER AND MOULDER

Model : GN-7S23

MÁY BÀO 4 MẶT 5 TRỤC CAO TỐC CÓ ĐƯA PHÔI

MÁY BÀO 4 MẶT 6 TRỤC - TRỤC XOAY

4 SIDE PLANER AND 8 MOULDER

4 SIDE PLANER WITH 4 KNIFE SHAFTS

FOUR SIDED 6-AXIS PLANER MACHINE

4 SIDE PLANER 4 SPINDLE MACHINE

FOUR SIDE PLANER SIX KNIFE MACHIE

FOUR SIDE PLANER MACHINE
