Function
Pre – milling Bevel milling A Gluing – IR Drying Notch Banding strip grooving Edge pressure rubber belt press B Gluing – Heating Edge pressure rubber belt press End trimming Top and bottom trimming Conner trimming Scraping Flat scrap Cleaning – Bufing
Specifications
Straight edge milling motor	: 1.8 Kw x 2
Inclined milling motor	: 4 Kw
Head and tail cutting motor	: 0.37 Kw x 2
Rough trimming motor	: 0.75 Kw x 2
Fine trimming motor	: 0.75 Kw x 2
Polishing motor	: 0.37 Kw x 2
Corner motor	: 0.3 Kw x 2
Inclined roller conveyor	: 0.75 Kw
Straight roller conveyor	: 0.75 Kw
Motor lifting able	: 0.37 Kw
Conveyor motor	: 5.5 kw
Working speed	: 12 – 20 m/phút
Working thickness gluing at an angle	: 15-25 mm
Working thickness gluing straight	: 10-45 mm
Workpiece thickness	: 10 – 60 mm
Splint thickness	: 0.4 – 3 mm
Workpiece width	: ≥ 80 mm
Compressed air	: 0.6 - 0.8 Mpa
Machine size	: 11800 x 1150 x 800 mm
Weight	: 3800 kg
