Specifications
Straight milling motor	: 1.8 kw x 2
Gluing motor power	: 0.75 kw
Heating motor	: 1.5 kw
Ending trimming motor	: 0.55 kw x 2
Fine trimming motor	: 1.1 kw x 2
Cornering motor	: 0.55 kw x 2
Polishing motor	: 0.37 kw x 2
Conveyor motor	: 2.2 kw
Working speed	: 12-20 m/min
Max. working thickness	: 10-60 mm
Min. working length	: 150 mm
Edge banding tape thickness	: 0.4-3 mm
Panel width	: 60 mm
Air pressure	: 0.7 Mpa
Machine size	: 6700 x 1000 x 1200 mm
Net weight	: 2500 kg

AUTOMATIC EDGE BANDING MACHINE

AUTOMATIC EDGE BANDING MACHINE

Model: MICHAEL 4CR/B

SEMI-J EDGE BANDING MACHINE

FULLY AUTOMATIC SOFTFORMING EDGE BANDER J SHAPE

BEVELED AND STRAIGHT EDGE BANDING MACHINE

APPLIES FULL AUTOMATIC EDGE BANDING MACHINE

DOUBLE SIDES EDGE BANDING MACHINE

DOUBLE SIDES EDGE BANDING MACHINE

MÁY DÁN CẠNH CHỮ J/C PUR VÀ EVA

MÁY DÁN CẠNH TỰ ĐỘNG ĐA NĂNG
