Specifications
Number of universal driving CNC shafts	03 (X,Y,Z)
Saw blade specification	5340x16 x 0.8mm
Saw wheel diameter	760mm
Saw blade rotation angle	+90^o -90^o
Spondle power	7.5kw
Max.working speed	0-20m/min
Max.retraction speed	40m/min
X-axis servo motor	1.0kw
Y-axis servo motor	1.0kw
Z-axis servo motor	0.4kw x 2
Max.working size	1200 x 1250mm
Minimum turning radius	R=60mm
Working air pressure	6kg/cm²
Dust suction inlet	100mm x 2
Electrical cubicle sizes	1050 x 550 x 1800
Machine sizes	2800x2200x1700 mm
Machine head sizes	1000 x 900 x 2500 mm
Video

CNC BAND SAW

CNC BAND SAW

Model: SDJ-1200
