Specifications
Max.working width	: 635mm ( 25" )
Max.working thickness	: 200mm ( 8" )
Min.working thickness	: 10m
Min.working lenght	: 310mm
Knife Nos. On Bottom Cutterhead	: 156pcs
Knife Sizes	: TCT 15x15x2.5mm
Cutterhead Diameter	: Ø126mm
Spindle speed	: 5000RPM
Feeding speed	: 8-24m/min
Dust Hood Outlet Diameter	: 6" X 2
Table Surface Area	: 27"x103"
Top Cutterhead Drive Motor	: 20( 25HP)
Buttom Cutterhead Drive Motor	: 15( 20HP)
Feeding Motor	: 3HP
Elevation Motor	: 1/2HP
Machine size	: 2700x1145x1720mm
Net Weight	: 3000kg
Packing size	: 2780x1240x1940mm
Gross Weight	: 3500kg
