Features
- Can be maching end mortise, straight mortise, belt mortise and other tenon shapes can be finished in one machine. - Quality precision mortise products - High power mortise motor, X Y axis motion is controlled by high-speed servo motor - Alternating working method of two tables is adopted to improve production efficiency. - The equipment uses the manual display, woker just need to enter the parameter of the product to be processed on the screen, simple, convenient and highly practical.
Specifications
Spindle speed	: 18000 r/min
Spindle motor	: 4.5 kw
Servo motor X	: 0.75 kw
Servo motor Y	: 0.75 kw
Total power	: 6 kw
Working width	: 600 mm
Working thickness	: 5-35 mm
Tenoning space	: can adjust
Process cycle	: 3-30 s
Net weight	: 589 kg
Machine size	: 1470 x 895 x 1165 mm

DOVETAIL TENON MACHINE 600MM

DOVETAIL TENON MACHINE 600MM

Model: CNC 600A
