Specifications
Travel X Axis	: 1100 mm	: 1200 mm
Travel Y Axis	: 1200 mm	: 2000 mm
Travel Z Axis	: 220 mm	: 220 mm
Min. distance between two spindle	: 200mm	: 200 mm
Spindle speed	: 18000 rpm	: 18000 rpm
Spindle Motor	: 3.7 KW x 4	: 3.7 KW x 4
Travel servo motor	: 0.85 KW x 3	: 0.85 KW x 3
Total power	: 18 Kw	: 18 Kw
Machine dimension	: 2300 x 2230 x 1900 mm	: 3230 x 2230 x 1900 mm
Net weight	: 1300 kgs	: 1900 kgs
Video

OSCILLATION MORTISER RECTANGULAR TENONER CNC

OSCILLATION MORTISER RECTANGULAR TENONER CNC

Model: SDC-1200-4-4/ SDC-2000-4-4
