Features
Equipped with 6 machining axes to improve working efficiency Fast roll speed Maximum working thickness 120mm Smart touch screen control, easy to operate Using shihlin inverter
Specification
Feeding speed	: 0 – 18 m/min
Working thickness	: 3 – 120 mm
Conveyor motor	: 3 Kw
Shaft steel wire 1:
Steel wire diameter	: 0,3 mm
Motor	: 7.5 Kw
Shaft steel wire 2,3:
Steel wire diameter	: 0,25 mm
Motor	: 1.5 Kw
Shaft steel wire 4:
Steel wire diameter	: 0,3 mm
Motor	:7.5 Kw
Shaft steel wire 5:
Steel wire diameter	: 0.2 mm
Motor	: 5.5 Kw
Shaft steel wire 6:
Steel wire diameter	: 0.8 mm
Motor	: 5.5 Kw
Total auxiliary power	: 6.6 Kw
Power	: 66 Kw
Net wight	: 5200 Kg
Machine size	: 3710 x 2750 x 1750 mm
