The machine base is manufactured from high quality cast iron. (FC 25-30) Major components and machine frame are made from high grade cast-iron. A hydraulically operated model. Hydraulic control system. Multiple spindles can be easily adjusted for various boring positions. Easy operation and minimum maintenance.
Specifications
Spindle motor	2 HP x 3
Spindle speed	3700 rpm
Number of spindle	16 pcs
Number of idler wheel	8
Hold down clamp	6 pcs
Table area	900 x 2400 mm
Hydraulic pump motor	2 HP
Max table travel	100 mm
Max boring depth	90 mm
Min.distance between drills	50mm
Machine size	2700 x 1810 x 1800 mm
Net weight	1500 kgs
Gross weight	1720 kgs

HYDRAULIC VERTICAL MULTIPLE SPINDLE BORING

HYDRAULIC VERTICAL MULTIPLE SPINDLE BORING

Model: SV - 308
