Processing size range
Min. Width of work-piece	: 50 mm
Max. Width of work-piece	: 1200 mm
Max. Length of work-piece	: 5000 mm
Min. Length of work-piece	: 300 mm
Max. Thickness of work-piece	: 48 mm
Min. Thickness of work-piece	: 10 mm
Working Stoke & Max. Position speed
X axis	: 5410 mm, 130 m/min
Y axis	: 1700 mm, 80 m/min
Z axis	: 140 mm, 30 m/min
U axis	: 5410 mm, 130 m/min
V axis	: 1395mm, 80 m/min
W axis	: 110 mm, 30 m/min
A axis	: 1235 mm, 30 m/min
Top Drilling unit
Vertical spindles	: 12
Horizontal	: 4 ( X axis) + 4 ( Y axis)
Drilling box motor speed	: 2800 rpm
Router motor power	: 3.5kw speed 18000 rpm
Bottom drilling unit
Vertical spindles	: 9
Horizontal	: 0
Drilling box motor speed	: 2800 rpm
Router motor power	: 3.5 kw speed 18000 rpm
Other data
Working table height	: 960 mm
Total power	: 20.45 kw
Weight	: 4000 kg
Operation eare size	: 7800 x 2840 x 2200 mm
Video

SIX CNC BORING MACHINE

SIX CNC BORING MACHINE

Model: SM-612HZ
