DOUBLE SURFACE PLANER 1M
DOUBLE SURFACE PLANER 1M
Model: GTM-1020W
| Features: | |
|
• The four table rollers provide superior feeding performance
• Standard Y-delta motor starting
• Quick belt change for bottom cutterhead
• Automatic lubrication for feeding chain
• Automatic lubricator provides convenient lubrication to caterpillar chain slideways
• An air wrench is applied for removing or installing knives and saves knife change time.
• The upper and lower cutter heads are spiral cutter heads
• The table surface is hard chrome plated and precision ground for extremely smooth feeding and maximum wear resistance
• The dovetailed slideways on the table elevation assure outstanding rigidity and stability
• Sectional infeed rollers
• Maximum cutting width up to 1,020mm
|
|
|
Specifications
|
|
|
Maximum Width Of Cut
|
1020mm
|
|
Maximum Thickness Of Cut
|
200mm
|
|
Minmum Thickness Of Cut
|
10mm
|
|
Minmum Lenght Of Cut
|
310mm
|
|
Knife Nos. On Top Cutterhead
|
328 cái
|
|
Knife Nos. On Bottom Cutterhead
|
328 cái
|
|
Knife Sizes
|
TCT 15x15x2.5mm
|
|
CutterHead Speed
|
4000 vòng/phút
|
|
Variable Feed Speed-inverter
|
8-24m/phút
|
|
Dust Hood Outlet Diameter
|
152mm x 4
|
|
Table Surface Area
|
1016x2616 mm
|
|
Top Cutterhead Drive Motor
|
40(50)HP
|
|
Buttom Cutterhead Drive Motor
|
30(40)HP
|
|
Feed Drive Motor
|
7.5HP
|
|
Upper Mechanism Elevation Motor
|
1HP
|
|
Machine Dimensions
|
2750x1950x1900mm
|
|
Net Weight
|
6300kg
|
|
Packing Dimensions
|
2850x2050x2050mm
|
|
Gross Weight
|
7000kg
|
